Technical Specifications of IPB47N10SL-26
| Datasheet |  IPB47N10SL-26 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | SIPMOS? |
|---|
| Packaging | Cut Tape (CT) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Logic Level Gate |
|---|
| Drain to Source Voltage (Vdss) | 100V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 47A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 26 mOhm @ 33A, 10V |
|---|
| Vgs(th) (Max) @ Id | 2V @ 2mA |
|---|
| Gate Charge (Qg) @ Vgs | 135nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 2500pF @ 25V |
|---|
| Power - Max | 175W |
|---|
| Operating Temperature | -55°C ~ 175°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Supplier Device Package | PG-TO263-3-2 |
|---|
We can supply Infineon Technologies part# IPB47N10SL-26. Use the request quote form to request IPB47N10SL-26 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IPB47N10SL-26. The price and lead time for IPB47N10SL-26 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IPB47N10SL-26. We look forward to doing business with you.
