TPC8048-H(TE12L,Q)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TPC8048-H(TE12L,Q) |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET N-CH 60V 16A 8-SOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TPC8048-H(TE12L,Q) Price |  |
Technical Specifications of TPC8048-H(TE12L,Q)
| Datasheet |  TPC8048-H(TE12L,Q) datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Cut Tape (CT) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 60V |
| Current - Continuous Drain (Id) @ 25°C | 16A (Ta) |
| Rds On (Max) @ Id, Vgs | 6.9 mOhm @ 8A, 10V |
| Vgs(th) (Max) @ Id | 2.3V @ 1mA |
| Gate Charge (Qg) @ Vgs | 87nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 7540pF @ 10V |
| Power - Max | - |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.173", 4.40mm Width) |
| Supplier Device Package | 8-SOP (5.5x6.0) |
