NP48N055MLE-S18-AY
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | NP48N055MLE-S18-AY |
|---|---|
| Manufacturer | Renesas Electronics America |
| Description | MOSFET N-CH 55V 48A TO-220 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| NP48N055MLE-S18-AY Price |  |
Technical Specifications of NP48N055MLE-S18-AY
| Datasheet |  NP48N055MLE-S18-AY datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Renesas Electronics America |
| Series | - |
| Packaging | Tube |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 55V |
| Current - Continuous Drain (Id) @ 25°C | 48A (Tc) |
| Rds On (Max) @ Id, Vgs | 17 mOhm @ 24A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250μA |
| Gate Charge (Qg) @ Vgs | 60nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 3000pF @ 25V |
| Power - Max | 1.8W |
| Operating Temperature | 175°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | TO-220-3 |
