SSM6J206FE(TE85L,F
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | SSM6J206FE(TE85L,F |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET P-CH 20V 2A ES6 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| SSM6J206FE(TE85L,F Price |  |
Technical Specifications of SSM6J206FE(TE85L,F
| Category | Discrete Semiconductor Products |
|---|---|
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET P-Channel, Metal Oxide |
| FET Feature | Logic Level Gate, 1.8V Drive |
| Drain to Source Voltage (Vdss) | 20V |
| Current - Continuous Drain (Id) @ 25°C | 2A (Ta) |
| Rds On (Max) @ Id, Vgs | 130 mOhm @ 1A, 4V |
| Vgs(th) (Max) @ Id | 1V @ 1mA |
| Gate Charge (Qg) @ Vgs | - |
| Input Capacitance (Ciss) @ Vds | 335pF @ 10V |
| Power - Max | 500mW |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SOT-563, SOT-666 |
| Supplier Device Package | ES6 (1.6x1.6) |
