NP100N055PUK-E1-AY
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | NP100N055PUK-E1-AY |
|---|---|
| Manufacturer | Renesas Electronics America |
| Description | MOSFET N-CH 55V 100A TO-263 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| NP100N055PUK-E1-AY Price |  |
Technical Specifications of NP100N055PUK-E1-AY
| Datasheet |  NP100N055PUK-E1-AY datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Renesas Electronics America |
| Series | - |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 55V |
| Current - Continuous Drain (Id) @ 25°C | 100A (Tc) |
| Rds On (Max) @ Id, Vgs | 3.25 mOhm @ 50A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 250μA |
| Gate Charge (Qg) @ Vgs | 120nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 7350pF @ 25V |
| Power - Max | 1.8W |
| Operating Temperature | 175°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
| Supplier Device Package | TO-263 (D2Pak) |
