BSF077N06NT3GXUMA1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | BSF077N06NT3GXUMA1 |
|---|---|
| Manufacturer | Infineon Technologies |
| Description | MOSFET N-CH 60V 13A WDSON-2 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| BSF077N06NT3GXUMA1 Price |  |
Technical Specifications of BSF077N06NT3GXUMA1
| Category | Discrete Semiconductor Products |
|---|---|
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Infineon Technologies |
| Series | OptiMOS? |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 60V |
| Current - Continuous Drain (Id) @ 25°C | 13A (Ta), 56A (Tc) |
| Rds On (Max) @ Id, Vgs | 7.7 mOhm @ 30A, 10V |
| Vgs(th) (Max) @ Id | 4V @ 33μA |
| Gate Charge (Qg) @ Vgs | 46nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 3700pF @ 30V |
| Power - Max | 38W |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 3-WDSON |
| Supplier Device Package | MG-WDSON-2, CanPAK M? |
