BSF050N03LQ3GXUMA1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | BSF050N03LQ3GXUMA1 |
|---|---|
| Manufacturer | Infineon Technologies |
| Description | MOSFET N-CH 30V 60A 2WDSON |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| BSF050N03LQ3GXUMA1 Price |  |
Technical Specifications of BSF050N03LQ3GXUMA1
| Category | Discrete Semiconductor Products |
|---|---|
| Family | Transistors - FETs, MOSFETs - Single |
| Manufacturer | Infineon Technologies |
| Series | OptiMOS? |
| Packaging | Tape & Reel (TR) |
| FET Type | MOSFET N-Channel, Metal Oxide |
| FET Feature | Standard |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 15A (Ta), 60A (Tc) |
| Rds On (Max) @ Id, Vgs | 5 mOhm @ 20A, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 250μA |
| Gate Charge (Qg) @ Vgs | 42nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 3000pF @ 15V |
| Power - Max | 2.2W |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 3-WDSON |
| Supplier Device Package | MG-WDSON-2, CanPAK M? |
