Technical Specifications of STB23NM60ND
| Datasheet |  STB23NM60ND datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | STMicroelectronics |
|---|
| Series | FDmesh? II |
|---|
| Packaging | Digi-Reel? |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 600V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 19.5A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 180 mOhm @ 10A, 10V |
|---|
| Vgs(th) (Max) @ Id | 5V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 70nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 2050pF @ 50V |
|---|
| Power - Max | 150W |
|---|
| Operating Temperature | 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Supplier Device Package | D2PAK |
|---|
We can supply STMicroelectronics part# STB23NM60ND. Use the request quote form to request STB23NM60ND pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number STB23NM60ND. The price and lead time for STB23NM60ND depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# STB23NM60ND. We look forward to doing business with you.
