Technical Specifications of FGH40T65SPD_F085
| Datasheet |  FGH40T65SPD_F085 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | Automotive, AEC-Q101 |
|---|
| Packaging | Tube |
|---|
| IGBT Type | NPT |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 650V |
|---|
| Current - Collector (Ic) (Max) | 80A |
|---|
| Current - Collector Pulsed (Icm) | 120A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 40A |
|---|
| Power - Max | 267W |
|---|
| Switching Energy | 1.16MJ (on), 270μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 36nC |
|---|
| Td (on/off) @ 25°C | 18ns/35ns |
|---|
| Test Condition | 400V, 40A, 6 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | * |
|---|
| Package / Case | TO-247-3 |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-247 |
|---|
We can supply Fairchild Semiconductor part# FGH40T65SPD_F085. Use the request quote form to request FGH40T65SPD_F085 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FGH40T65SPD_F085. The price and lead time for FGH40T65SPD_F085 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FGH40T65SPD_F085. We look forward to doing business with you.
