Technical Specifications of IRG4IBC30KDPBF
| Datasheet |  IRG4IBC30KDPBF datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | - |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 600V |
|---|
| Current - Collector (Ic) (Max) | 17A |
|---|
| Current - Collector Pulsed (Icm) | 34A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.7V @ 15V, 16A |
|---|
| Power - Max | 45W |
|---|
| Switching Energy | 600μJ (on), 580μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 67nC |
|---|
| Td (on/off) @ 25°C | 60ns/160ns |
|---|
| Test Condition | 480V, 16A, 23 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 42ns |
|---|
| Package / Case | TO-220-3 Full Pack |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-220AB Full-Pak |
|---|
We can supply Infineon Technologies part# IRG4IBC30KDPBF. Use the request quote form to request IRG4IBC30KDPBF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IRG4IBC30KDPBF. The price and lead time for IRG4IBC30KDPBF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IRG4IBC30KDPBF. We look forward to doing business with you.
