Technical Specifications of FGA15N120ANTDTU_F109
| Datasheet |  FGA15N120ANTDTU_F109 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | NPT and Trench |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
|---|
| Current - Collector (Ic) (Max) | 30A |
|---|
| Current - Collector Pulsed (Icm) | 45A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 15A |
|---|
| Power - Max | 186W |
|---|
| Switching Energy | 3mJ (on), 600μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 120nC |
|---|
| Td (on/off) @ 25°C | 15ns/160ns |
|---|
| Test Condition | 600V, 15A, 10 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 330ns |
|---|
| Package / Case | TO-3P-3, SC-65-3 |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-3PN |
|---|
We can supply Fairchild Semiconductor part# FGA15N120ANTDTU_F109. Use the request quote form to request FGA15N120ANTDTU_F109 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FGA15N120ANTDTU_F109. The price and lead time for FGA15N120ANTDTU_F109 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FGA15N120ANTDTU_F109. We look forward to doing business with you.
