Technical Specifications of STGD7NB120S-1
| Datasheet |  STGD7NB120S-1 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | STMicroelectronics |
|---|
| Series | PowerMESH? |
|---|
| Packaging | Tube |
|---|
| IGBT Type | - |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
|---|
| Current - Collector (Ic) (Max) | 10A |
|---|
| Current - Collector Pulsed (Icm) | 20A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.1V @ 15V, 7A |
|---|
| Power - Max | 55W |
|---|
| Switching Energy | 15mJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 29nc |
|---|
| Td (on/off) @ 25°C | 570ns/- |
|---|
| Test Condition | 960V, 7A, 1 kOhm, 15V |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Package / Case | TO-251-3 Short Leads, IPak, TO-251AA |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | I-Pak |
|---|
We can supply STMicroelectronics part# STGD7NB120S-1. Use the request quote form to request STGD7NB120S-1 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number STGD7NB120S-1. The price and lead time for STGD7NB120S-1 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# STGD7NB120S-1. We look forward to doing business with you.
