Technical Specifications of IXBH10N300HV
| Datasheet |  IXBH10N300HV datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | IXYS |
|---|
| Series | BIMOSFET? |
|---|
| Packaging | Tube |
|---|
| IGBT Type | - |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 3000V |
|---|
| Current - Collector (Ic) (Max) | 34A |
|---|
| Current - Collector Pulsed (Icm) | 88A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.8V @ 15V, 10A |
|---|
| Power - Max | 180W |
|---|
| Switching Energy | - |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 46nC |
|---|
| Td (on/off) @ 25°C | 36ns/100ns |
|---|
| Test Condition | 960V, 10A, 10 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 1.6μs |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | TO-263 |
|---|
We can supply IXYS part# IXBH10N300HV. Use the request quote form to request IXBH10N300HV pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IXBH10N300HV. The price and lead time for IXBH10N300HV depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IXBH10N300HV. We look forward to doing business with you.
