Technical Specifications of AFC0948DE-TP20
| Datasheet |  AFC0948DE-TP20 datasheet |
|---|
| Category | Fans, Thermal Management |
|---|
| Family | DC Fans |
|---|
| Manufacturer | Delta Electronics |
|---|
| Series | AFC |
|---|
| Voltage - Rated | 48VDC |
|---|
| Size / Dimension | Square - 92mm L x 92mm H |
|---|
| Width | 38mm |
|---|
| Air Flow | 159.4 CFM (4.51m3/min) |
|---|
| Static Pressure | 1.528 in H2O (380.6 Pa) |
|---|
| Bearing Type | Ball |
|---|
| Fan Type | Tubeaxial |
|---|
| Features | PWM Control; Speed Sensor (Tach) |
|---|
| Noise | 67 dB(A) |
|---|
| Power (Watts) | 28.8W |
|---|
| RPM | 7500 RPM |
|---|
| Termination | 4 Wire Leads |
|---|
| Ingress Protection | - |
|---|
| Operating Temperature | -40 ~ 149°F (-40 ~ 65°C) |
|---|
| Approvals | CE, TUV, UL |
|---|
| Current Rating | 0.600A |
|---|
| Voltage Range | 36 ~ 75VDC |
|---|
| Material - Frame | Plastic |
|---|
| Material - Blade | Plastic |
|---|
| Weight | 0.573 lb (259.91g) |
|---|
We can supply Delta Electronics part# AFC0948DE-TP20. Use the request quote form to request AFC0948DE-TP20 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AFC0948DE-TP20. The price and lead time for AFC0948DE-TP20 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# AFC0948DE-TP20. We look forward to doing business with you.
