Technical Specifications of FDD1-17251DBMW3C-L56
| Datasheet |  FDD1-17251DBMW3C-L56 datasheet |
|---|
| Category | Fans, Thermal Management |
|---|
| Family | DC Fans |
|---|
| Manufacturer | Qualtek |
|---|
| Series | HPLC, FDD1-17251 |
|---|
| Voltage - Rated | 24VDC |
|---|
| Size / Dimension | Rectangular/Rounded - 172mm L x 151mm H |
|---|
| Width | 51mm |
|---|
| Air Flow | 290.0 CFM (8.21m3/min) |
|---|
| Static Pressure | 0.925 in H2O (230.4 Pa) |
|---|
| Bearing Type | Ball |
|---|
| Fan Type | Tubeaxial |
|---|
| Features | Alarm, Speed Sensor (Tach) |
|---|
| Noise | 60 dB(A) |
|---|
| Power (Watts) | 29W |
|---|
| RPM | 3600 RPM |
|---|
| Termination | 4 Wire Leads |
|---|
| Ingress Protection | IP56M - Dust Protected, Water Resistant |
|---|
| Operating Temperature | -4 ~ 158°F (-20 ~ 70°C) |
|---|
| Approvals | CE, TUV, UL |
|---|
| Current Rating | 1.21A |
|---|
| Voltage Range | - |
|---|
| Material - Frame | Aluminum |
|---|
| Material - Blade | Plastic |
|---|
| Weight | 2.5 lbs (1.1kg) |
|---|
We can supply Qualtek part# FDD1-17251DBMW3C-L56. Use the request quote form to request FDD1-17251DBMW3C-L56 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FDD1-17251DBMW3C-L56. The price and lead time for FDD1-17251DBMW3C-L56 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FDD1-17251DBMW3C-L56. We look forward to doing business with you.
