Technical Specifications of OD1232-24MSS01A
| Datasheet |  OD1232-24MSS01A datasheet |
|---|
| Category | Fans, Thermal Management |
|---|
| Family | DC Fans |
|---|
| Manufacturer | Orion Fans |
|---|
| Series | OD1232 |
|---|
| Voltage - Rated | 24VDC |
|---|
| Size / Dimension | Square - 120mm L x 120mm H |
|---|
| Width | 32.00mm |
|---|
| Air Flow | 107.0 CFM (3.03m3/min) |
|---|
| Static Pressure | 0.330 in H2O (82.2 Pa) |
|---|
| Bearing Type | Sealed Sleeve |
|---|
| Fan Type | Tubeaxial |
|---|
| Features | Speed Sensor (Tach) |
|---|
| Noise | 48 dB |
|---|
| Power (Watts) | - |
|---|
| RPM | 3300 RPM |
|---|
| Termination | 3 Wire Leads |
|---|
| Ingress Protection | - |
|---|
| Operating Temperature | 14 ~ 122°F (-10 ~ 50°C) |
|---|
| Approvals | * |
|---|
| Current Rating | 0.280A |
|---|
| Voltage Range | 12 ~ 27.8VDC |
|---|
| Material - Frame | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
|---|
| Material - Blade | Polybutylene Terephthalate (PBT), Fiberglass Reinforced |
|---|
| Weight | - |
|---|
We can supply Orion Fans part# OD1232-24MSS01A. Use the request quote form to request OD1232-24MSS01A pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number OD1232-24MSS01A. The price and lead time for OD1232-24MSS01A depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# OD1232-24MSS01A. We look forward to doing business with you.
