Technical Specifications of CL-25-50
| Datasheet |  CL-25-50 datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Signal Transformer |
|---|
| Series | CL |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 1.2mH |
|---|
| Inductance - Connected In Parallel | 300μH |
|---|
| Tolerance | - |
|---|
| Current Rating - Parallel | 50A |
|---|
| Current Rating - Series | 25A |
|---|
| Current Saturation - Parallel | - |
|---|
| Current Saturation - Series | - |
|---|
| DC Resistance (DCR) - Parallel | 3 mOhm |
|---|
| DC Resistance (DCR) - Series | 12 mOhm |
|---|
| Shielding | Unshielded |
|---|
| Operating Temperature | - |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 3.870" L x 3.374" W (98.30mm x 85.70mm) |
|---|
| Height | 3.374" (85.70mm) |
|---|
We can supply Signal Transformer part# CL-25-50. Use the request quote form to request CL-25-50 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CL-25-50. The price and lead time for CL-25-50 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CL-25-50. We look forward to doing business with you.
