Technical Specifications of PF0552.102NLT
| Datasheet |  PF0552.102NLT datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Pulse Electronics Corporation |
|---|
| Series | PF0552NL |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 3.6μH |
|---|
| Inductance - Connected In Parallel | 910nH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating - Parallel | 12.9A |
|---|
| Current Rating - Series | 6.5A |
|---|
| Current Saturation - Parallel | 24A |
|---|
| Current Saturation - Series | 11.8A |
|---|
| DC Resistance (DCR) - Parallel | 2.4 mOhm Max |
|---|
| DC Resistance (DCR) - Series | 9.6 mOhm Max |
|---|
| Shielding | Shielded |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.492" L x 0.492" W (12.50mm x 12.50mm) |
|---|
| Height | 0.236" (6.00mm) |
|---|
We can supply Pulse Electronics Corporation part# PF0552.102NLT. Use the request quote form to request PF0552.102NLT pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PF0552.102NLT. The price and lead time for PF0552.102NLT depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PF0552.102NLT. We look forward to doing business with you.
