Technical Specifications of CDRCH12D78BNP-101MC
| Datasheet |  CDRCH12D78BNP-101MC datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Sumida America Components Inc. |
|---|
| Series | CDRCH12D78B |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 440μH |
|---|
| Inductance - Connected In Parallel | 100μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating - Parallel | 1.6A |
|---|
| Current Rating - Series | 780mA |
|---|
| Current Saturation - Parallel | 3.1A |
|---|
| Current Saturation - Series | 1.55A |
|---|
| DC Resistance (DCR) - Parallel | 192 mOhm Max |
|---|
| DC Resistance (DCR) - Series | 768 mOhm Max |
|---|
| Shielding | Shielded |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.480" L x 0.480" W (12.20mm x 12.20mm) |
|---|
| Height | 0.315" (8.00mm) |
|---|
We can supply Sumida America Components Inc. part# CDRCH12D78BNP-101MC. Use the request quote form to request CDRCH12D78BNP-101MC pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CDRCH12D78BNP-101MC. The price and lead time for CDRCH12D78BNP-101MC depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CDRCH12D78BNP-101MC. We look forward to doing business with you.
