Technical Specifications of CTX2-3P-R
| Datasheet |  CTX2-3P-R datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Eaton |
|---|
| Series | Econo-Pac? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 7.4μH |
|---|
| Inductance - Connected In Parallel | 1.85μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating - Parallel | 4.6A |
|---|
| Current Rating - Series | 2.3A |
|---|
| Current Saturation - Parallel | - |
|---|
| Current Saturation - Series | - |
|---|
| DC Resistance (DCR) - Parallel | 11 mOhm Max |
|---|
| DC Resistance (DCR) - Series | 45 mOhm Max |
|---|
| Shielding | Unshielded |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.550" L x 0.550" W (13.97mm x 13.97mm) |
|---|
| Height | 0.190" (4.83mm) |
|---|
We can supply Eaton part# CTX2-3P-R. Use the request quote form to request CTX2-3P-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CTX2-3P-R. The price and lead time for CTX2-3P-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CTX2-3P-R. We look forward to doing business with you.
