Technical Specifications of PM610-05-RC
| Datasheet |  PM610-05-RC datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Bourns Inc. |
|---|
| Series | PM610 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Number of Coils | 6 |
|---|
| Inductance - Connected In Series | 417.6μH |
|---|
| Inductance - Connected In Parallel | 11.6μH |
|---|
| Tolerance | - |
|---|
| Current Rating - Parallel | 4.08A |
|---|
| Current Rating - Series | 680mA |
|---|
| Current Saturation - Parallel | 7.8A |
|---|
| Current Saturation - Series | 1.3A |
|---|
| DC Resistance (DCR) - Parallel | 34 mOhm |
|---|
| DC Resistance (DCR) - Series | 1.212 Ohm |
|---|
| Shielding | Unshielded |
|---|
| Operating Temperature | -40°C ~ 105°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 12-SMD |
|---|
| Size / Dimension | 0.591" L x 0.630" W (15.00mm x 16.00mm) |
|---|
| Height | 0.307" (7.80mm) |
|---|
We can supply Bourns Inc. part# PM610-05-RC. Use the request quote form to request PM610-05-RC pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PM610-05-RC. The price and lead time for PM610-05-RC depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PM610-05-RC. We look forward to doing business with you.
