Technical Specifications of PM3602-5-B-RC
| Datasheet |  PM3602-5-B-RC datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Arrays, Signal Transformers |
|---|
| Manufacturer | Bourns Inc. |
|---|
| Series | PM3600 |
|---|
| Packaging | Bulk |
|---|
| Part Status | Obsolete |
|---|
| Number of Coils | 2 |
|---|
| Inductance - Connected In Series | 20μH |
|---|
| Inductance - Connected In Parallel | 5μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating - Parallel | 2.41A |
|---|
| Current Rating - Series | 1.2A |
|---|
| Current Saturation - Parallel | - |
|---|
| Current Saturation - Series | - |
|---|
| DC Resistance (DCR) - Parallel | 23 mOhm Max |
|---|
| DC Resistance (DCR) - Series | 92 mOhm Max |
|---|
| Shielding | Unshielded |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.452" L x 0.354" W (11.48mm x 8.99mm) |
|---|
| Height | 0.225" (5.72mm) |
|---|
We can supply Bourns Inc. part# PM3602-5-B-RC. Use the request quote form to request PM3602-5-B-RC pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PM3602-5-B-RC. The price and lead time for PM3602-5-B-RC depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PM3602-5-B-RC. We look forward to doing business with you.
