Technical Specifications of CDRH4D22HPNP-390MC
| Datasheet |  CDRH4D22HPNP-390MC datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Sumida America Components Inc. |
|---|
| Series | CDRH4D22/HP |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 39μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 520mA |
|---|
| Current - Saturation | 750mA |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 667.9 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 100°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.185" L x 0.185" W (4.70mm x 4.70mm) |
|---|
| Height - Seated (Max) | 0.094" (2.40mm) |
|---|
We can supply Sumida America Components Inc. part# CDRH4D22HPNP-390MC. Use the request quote form to request CDRH4D22HPNP-390MC pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CDRH4D22HPNP-390MC. The price and lead time for CDRH4D22HPNP-390MC depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CDRH4D22HPNP-390MC. We look forward to doing business with you.
