Technical Specifications of SCIHP1338-5R6M
| Datasheet |  SCIHP1338-5R6M datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Signal Transformer |
|---|
| Series | SCIHP1338 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | - |
|---|
| Inductance | 5.6μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 9.5A |
|---|
| Current - Saturation | 16A |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 18 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 200kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.543" L x 0.508" W (13.80mm x 12.90mm) |
|---|
| Height - Seated (Max) | 0.150" (3.80mm) |
|---|
We can supply Signal Transformer part# SCIHP1338-5R6M. Use the request quote form to request SCIHP1338-5R6M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SCIHP1338-5R6M. The price and lead time for SCIHP1338-5R6M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SCIHP1338-5R6M. We look forward to doing business with you.
