Technical Specifications of CR75NP-560KC
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Sumida America Components Inc. |
|---|
| Series | CR75 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 56μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 940mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 240 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | 11MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 100°C |
|---|
| Frequency - Test | 2.52MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.307" L x 0.276" W (7.80mm x 7.00mm) |
|---|
| Height - Seated (Max) | 0.217" (5.50mm) |
|---|
We can supply Sumida America Components Inc. part# CR75NP-560KC. Use the request quote form to request CR75NP-560KC pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CR75NP-560KC. The price and lead time for CR75NP-560KC depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CR75NP-560KC. We look forward to doing business with you.
