Technical Specifications of TSL0709RA-470KR94-PF
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TDK Corporation |
|---|
| Series | TSL |
|---|
| Packaging | Tape & Box (TB) |
|---|
| Part Status | Last Time Buy |
|---|
| Type | - |
|---|
| Material - Core | - |
|---|
| Inductance | 47μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 940mA |
|---|
| Current - Saturation | 960mA |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 170 mOhm Max |
|---|
| Q @ Freq | 20 @ 2.52MHz |
|---|
| Frequency - Self Resonant | 7.6MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -20°C ~ 85°C |
|---|
| Frequency - Test | 1kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial |
|---|
| Size / Dimension | 0.303" Dia (7.70mm) |
|---|
| Height - Seated (Max) | 0.378" (9.60mm) |
|---|
We can supply TDK Corporation part# TSL0709RA-470KR94-PF. Use the request quote form to request TSL0709RA-470KR94-PF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TSL0709RA-470KR94-PF. The price and lead time for TSL0709RA-470KR94-PF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TSL0709RA-470KR94-PF. We look forward to doing business with you.
