Technical Specifications of S1812-274J
| Datasheet |  S1812-274J datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | S1812 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 270μH |
|---|
| Tolerance | ±5% |
|---|
| Current Rating | 135mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 11 Ohm Max |
|---|
| Q @ Freq | 40 @ 790kHz |
|---|
| Frequency - Self Resonant | 4MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 790kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 1812 (4532 Metric) |
|---|
| Size / Dimension | 0.190" L x 0.134" W (4.80mm x 3.40mm) |
|---|
| Height - Seated (Max) | 0.134" (3.40mm) |
|---|
We can supply API Delevan Inc. part# S1812-274J. Use the request quote form to request S1812-274J pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number S1812-274J. The price and lead time for S1812-274J depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# S1812-274J. We look forward to doing business with you.
