Technical Specifications of SC1812-680
| Datasheet |  SC1812-680 datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Signal Transformer |
|---|
| Series | SC1812 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 68μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 380mA |
|---|
| Current - Saturation | 220mA |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 2.21 Ohm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.189" L x 0.134" W (4.80mm x 3.40mm) |
|---|
| Height - Seated (Max) | 0.110" (2.80mm) |
|---|
We can supply Signal Transformer part# SC1812-680. Use the request quote form to request SC1812-680 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SC1812-680. The price and lead time for SC1812-680 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SC1812-680. We look forward to doing business with you.
