Technical Specifications of PG0926.223NL
| Datasheet |  PG0926.223NL datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Pulse Electronics Corporation |
|---|
| Series | PG0926NL |
|---|
| Packaging | Tray |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 22μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 7A |
|---|
| Current - Saturation | 6A |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 21 mOhm |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 130°C |
|---|
| Frequency - Test | - |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.528" L x 0.528" W (13.40mm x 13.40mm) |
|---|
| Height - Seated (Max) | 0.315" (8.00mm) |
|---|
We can supply Pulse Electronics Corporation part# PG0926.223NL. Use the request quote form to request PG0926.223NL pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PG0926.223NL. The price and lead time for PG0926.223NL depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PG0926.223NL. We look forward to doing business with you.
