Technical Specifications of SPM5012T-1R5M-LR
| Datasheet |  SPM5012T-1R5M-LR datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TDK Corporation |
|---|
| Series | SPM-LR |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Metal |
|---|
| Inductance | 1.5μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 3.8A |
|---|
| Current - Saturation | 6A |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 46.2 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.126" L x 0.118" W (3.20mm x 3.00mm) |
|---|
| Height - Seated (Max) | 0.047" (1.20mm) |
|---|
We can supply TDK Corporation part# SPM5012T-1R5M-LR. Use the request quote form to request SPM5012T-1R5M-LR pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SPM5012T-1R5M-LR. The price and lead time for SPM5012T-1R5M-LR depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SPM5012T-1R5M-LR. We look forward to doing business with you.
