Technical Specifications of SDR1006-560KL
| Datasheet |  SDR1006-560KL datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Bourns Inc. |
|---|
| Series | SDR1006 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 56μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 1.15A |
|---|
| Current - Saturation | 2.1A |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 190 mOhm Max |
|---|
| Q @ Freq | 20 @ 2.52MHz |
|---|
| Frequency - Self Resonant | 7.5MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 1kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.386" L x 0.386" W (9.80mm x 9.80mm) |
|---|
| Height - Seated (Max) | 0.228" (5.80mm) |
|---|
We can supply Bourns Inc. part# SDR1006-560KL. Use the request quote form to request SDR1006-560KL pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SDR1006-560KL. The price and lead time for SDR1006-560KL depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SDR1006-560KL. We look forward to doing business with you.
