Technical Specifications of PD54R-562M
| Datasheet |  PD54R-562M datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | PD54R |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 5.6μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 1.7A |
|---|
| Current - Saturation | 1.7A |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 85 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 7.96MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.224" L x 0.201" W (5.70mm x 5.11mm) |
|---|
| Height - Seated (Max) | 0.177" (4.50mm) |
|---|
We can supply API Delevan Inc. part# PD54R-562M. Use the request quote form to request PD54R-562M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PD54R-562M. The price and lead time for PD54R-562M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PD54R-562M. We look forward to doing business with you.
