Technical Specifications of SPM5015T-2R2M
| Datasheet |  SPM5015T-2R2M datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TDK Corporation |
|---|
| Series | SPM |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Metal |
|---|
| Inductance | 2.2μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 4.3A |
|---|
| Current - Saturation | 3.9A |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 49.5 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.213" L x 0.201" W (5.40mm x 5.10mm) |
|---|
| Height - Seated (Max) | 0.059" (1.50mm) |
|---|
We can supply TDK Corporation part# SPM5015T-2R2M. Use the request quote form to request SPM5015T-2R2M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SPM5015T-2R2M. The price and lead time for SPM5015T-2R2M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SPM5015T-2R2M. We look forward to doing business with you.
