Technical Specifications of S0402-22NJ1C
| Datasheet |  S0402-22NJ1C datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | S0402 |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Alumina |
|---|
| Inductance | 22nH |
|---|
| Tolerance | ±5% |
|---|
| Current Rating | 400mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 350 mOhm Max |
|---|
| Q @ Freq | 24 @ 250MHz |
|---|
| Frequency - Self Resonant | 2.8GHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 250MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 0402 (1005 Metric) |
|---|
| Size / Dimension | 0.043" L x 0.025" W (1.09mm x 0.64mm) |
|---|
| Height - Seated (Max) | 0.030" (0.76mm) |
|---|
We can supply API Delevan Inc. part# S0402-22NJ1C. Use the request quote form to request S0402-22NJ1C pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number S0402-22NJ1C. The price and lead time for S0402-22NJ1C depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# S0402-22NJ1C. We look forward to doing business with you.
