Technical Specifications of IMC2220ER2R2K
| Datasheet |  IMC2220ER2R2K datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Vishay Dale |
|---|
| Series | IMC-2220 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | - |
|---|
| Inductance | 2.2μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 1.3A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 60 mOhm Max |
|---|
| Q @ Freq | 10 @ 7.96MHz |
|---|
| Frequency - Self Resonant | 42MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 7.96MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 2220 (5650 Metric) |
|---|
| Size / Dimension | 0.221" L x 0.197" W (5.60mm x 5.00mm) |
|---|
| Height - Seated (Max) | 0.165" (4.20mm) |
|---|
We can supply Vishay Dale part# IMC2220ER2R2K. Use the request quote form to request IMC2220ER2R2K pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IMC2220ER2R2K. The price and lead time for IMC2220ER2R2K depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IMC2220ER2R2K. We look forward to doing business with you.
