Technical Specifications of SDS680R-683M
| Datasheet |  SDS680R-683M datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | SDS680R |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 68μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 400mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 290 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | 15MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.260" L x 0.175" W (6.60mm x 4.45mm) |
|---|
| Height - Seated (Max) | 0.115" (2.92mm) |
|---|
We can supply API Delevan Inc. part# SDS680R-683M. Use the request quote form to request SDS680R-683M pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SDS680R-683M. The price and lead time for SDS680R-683M depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SDS680R-683M. We look forward to doing business with you.
