Technical Specifications of ELC-11D3R3F
| Datasheet |  ELC-11D3R3F datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Panasonic Electronic Components |
|---|
| Series | ELC11D |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 3.3μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 4.9A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 15 mOhm |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | - |
|---|
| Frequency - Test | 10kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial, Vertical Cylinder |
|---|
| Size / Dimension | 0.453" Dia (11.50mm) |
|---|
| Height - Seated (Max) | 0.547" (13.90mm) |
|---|
We can supply Panasonic Electronic Components part# ELC-11D3R3F. Use the request quote form to request ELC-11D3R3F pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ELC-11D3R3F. The price and lead time for ELC-11D3R3F depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ELC-11D3R3F. We look forward to doing business with you.
