Technical Specifications of 4564R-271K
| Datasheet |  4564R-271K datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | 4564R |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 270μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 200mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 3 Ohm Max |
|---|
| Q @ Freq | 80 @ 796kHz |
|---|
| Frequency - Self Resonant | 2.6MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -20°C ~ 80°C |
|---|
| Frequency - Test | 796kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial |
|---|
| Size / Dimension | 0.340" Dia (8.64mm) |
|---|
| Height - Seated (Max) | 0.433" (11.00mm) |
|---|
We can supply API Delevan Inc. part# 4564R-271K. Use the request quote form to request 4564R-271K pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 4564R-271K. The price and lead time for 4564R-271K depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 4564R-271K. We look forward to doing business with you.
