Technical Specifications of ELC-12E101L
| Datasheet |  ELC-12E101L datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Panasonic Electronic Components |
|---|
| Series | 12E |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 100μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 1.3A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 140 mOhm |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | - |
|---|
| Frequency - Test | 10kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial |
|---|
| Size / Dimension | 0.512" Dia (13.00mm) |
|---|
| Height - Seated (Max) | 0.728" (18.50mm) |
|---|
We can supply Panasonic Electronic Components part# ELC-12E101L. Use the request quote form to request ELC-12E101L pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ELC-12E101L. The price and lead time for ELC-12E101L depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ELC-12E101L. We look forward to doing business with you.
