Technical Specifications of 5022R-271H
| Datasheet |  5022R-271H datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | 5022R |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | Phenolic |
|---|
| Inductance | 270nH |
|---|
| Tolerance | ±3% |
|---|
| Current Rating | 2.285A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 70 mOhm Max |
|---|
| Q @ Freq | 45 @ 25MHz |
|---|
| Frequency - Self Resonant | 400MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 25MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 2-SMD |
|---|
| Size / Dimension | 0.520" L x 0.250" W (13.21mm x 6.35mm) |
|---|
| Height - Seated (Max) | 0.230" (5.84mm) |
|---|
We can supply API Delevan Inc. part# 5022R-271H. Use the request quote form to request 5022R-271H pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 5022R-271H. The price and lead time for 5022R-271H depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 5022R-271H. We look forward to doing business with you.
