Technical Specifications of UP2C-150-R
| Datasheet |  UP2C-150-R datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Eaton |
|---|
| Series | UNI-PAC? 2C |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 15μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 3.17A |
|---|
| Current - Saturation | 3.17A |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 36.9 mOhm |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.507" L x 0.370" W (12.90mm x 9.40mm) |
|---|
| Height - Seated (Max) | 0.204" (5.20mm) |
|---|
We can supply Eaton part# UP2C-150-R. Use the request quote form to request UP2C-150-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number UP2C-150-R. The price and lead time for UP2C-150-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# UP2C-150-R. We look forward to doing business with you.
