Technical Specifications of NLV32T-2R2J-PFD
| Datasheet |  NLV32T-2R2J-PFD datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TDK Corporation |
|---|
| Series | NLV-PFD |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 2.2μH |
|---|
| Tolerance | ±5% |
|---|
| Current Rating | 320mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 1 Ohm Max |
|---|
| Q @ Freq | 30 @ 7.96MHz |
|---|
| Frequency - Self Resonant | 75MHz |
|---|
| Ratings | AEC-Q200 |
|---|
| Operating Temperature | -40°C ~ 105°C |
|---|
| Frequency - Test | 7.96MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 1210 (3225 Metric) |
|---|
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
|---|
| Height - Seated (Max) | 0.094" (2.40mm) |
|---|
We can supply TDK Corporation part# NLV32T-2R2J-PFD. Use the request quote form to request NLV32T-2R2J-PFD pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number NLV32T-2R2J-PFD. The price and lead time for NLV32T-2R2J-PFD depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# NLV32T-2R2J-PFD. We look forward to doing business with you.
