Technical Specifications of 2305-H-RC
| Datasheet |  2305-H-RC datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Bourns Inc. |
|---|
| Series | 2300 |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Toroidal |
|---|
| Material - Core | Powdered Iron |
|---|
| Inductance | 22μH |
|---|
| Tolerance | ±15% |
|---|
| Current Rating | 16.4A |
|---|
| Current - Saturation | - |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 7 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Frequency - Test | 1kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Radial |
|---|
| Size / Dimension | 1.280" Dia (32.51mm) |
|---|
| Height - Seated (Max) | 0.650" (16.51mm) |
|---|
We can supply Bourns Inc. part# 2305-H-RC. Use the request quote form to request 2305-H-RC pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 2305-H-RC. The price and lead time for 2305-H-RC depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 2305-H-RC. We look forward to doing business with you.
