Technical Specifications of 1331R-394K
| Datasheet |  1331R-394K datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | 1331R |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 390μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 46mA |
|---|
| Current - Saturation | 14mA |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 21 Ohm Max |
|---|
| Q @ Freq | 35 @ 790kHz |
|---|
| Frequency - Self Resonant | 7.8MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Frequency - Test | 790kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 2-SMD |
|---|
| Size / Dimension | 0.313" L x 0.115" W (7.95mm x 2.92mm) |
|---|
| Height - Seated (Max) | 0.145" (3.68mm) |
|---|
We can supply API Delevan Inc. part# 1331R-394K. Use the request quote form to request 1331R-394K pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 1331R-394K. The price and lead time for 1331R-394K depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 1331R-394K. We look forward to doing business with you.
