Technical Specifications of ER1641-683KP
| Datasheet |  ER1641-683KP datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | ER1641 |
|---|
| Packaging | Bulk |
|---|
| Part Status | Active |
|---|
| Type | Molded |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 68μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 180mA |
|---|
| Current - Saturation | - |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 2.44 Ohm Max |
|---|
| Q @ Freq | 50 @ 2.5MHz |
|---|
| Frequency - Self Resonant | 21MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Frequency - Test | 2.5MHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Axial |
|---|
| Size / Dimension | 0.162" Dia x 0.410" L (4.11mm x 10.41mm) |
|---|
| Height - Seated (Max) | - |
|---|
We can supply API Delevan Inc. part# ER1641-683KP. Use the request quote form to request ER1641-683KP pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number ER1641-683KP. The price and lead time for ER1641-683KP depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# ER1641-683KP. We look forward to doing business with you.
