Technical Specifications of 4307R-275K
| Datasheet |  4307R-275K datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | API Delevan Inc. |
|---|
| Series | 4307R |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Molded |
|---|
| Material - Core | Ferrite |
|---|
| Inductance | 2.7mH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 83mA |
|---|
| Current - Saturation | 25mA |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 47.3 Ohm Max |
|---|
| Q @ Freq | 50 @ 250kHz |
|---|
| Frequency - Self Resonant | 2.2MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Frequency - Test | 250kHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | Axial |
|---|
| Size / Dimension | 0.197" Dia x 0.447" L (5.00mm x 11.35mm) |
|---|
| Height - Seated (Max) | - |
|---|
We can supply API Delevan Inc. part# 4307R-275K. Use the request quote form to request 4307R-275K pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 4307R-275K. The price and lead time for 4307R-275K depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 4307R-275K. We look forward to doing business with you.
