Technical Specifications of LQH2HPN220MGRL
| Datasheet |  LQH2HPN220MGRL datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Murata Electronics North America |
|---|
| Series | LQH2HPN_GR |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 22μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 430mA |
|---|
| Current - Saturation | 460mA |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 1.63 Ohm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | 15MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Frequency - Test | 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 1008 (2520 Metric) |
|---|
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) |
|---|
| Height - Seated (Max) | 0.039" (1.00mm) |
|---|
We can supply Murata Electronics North America part# LQH2HPN220MGRL. Use the request quote form to request LQH2HPN220MGRL pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LQH2HPN220MGRL. The price and lead time for LQH2HPN220MGRL depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# LQH2HPN220MGRL. We look forward to doing business with you.
