Technical Specifications of UP2SC-6R8-R
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Eaton |
|---|
| Series | UNI-PAC? 2SC |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 6.8μH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 2.2A |
|---|
| Current - Saturation | 3.9A |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 55 mOhm Max |
|---|
| Q @ Freq | 70 @ 100kHz |
|---|
| Frequency - Self Resonant | 30MHz |
|---|
| Ratings | - |
|---|
| Operating Temperature | -25°C ~ 85°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.500" L x 0.394" W (12.70mm x 10.00mm) |
|---|
| Height - Seated (Max) | 0.204" (5.20mm) |
|---|
We can supply Eaton part# UP2SC-6R8-R. Use the request quote form to request UP2SC-6R8-R pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number UP2SC-6R8-R. The price and lead time for UP2SC-6R8-R depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# UP2SC-6R8-R. We look forward to doing business with you.
