Technical Specifications of MGDN2-00012
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | TE Connectivity |
|---|
| Series | MGDN2, Coev |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Obsolete |
|---|
| Type | Wirewound |
|---|
| Material - Core | - |
|---|
| Inductance | 56μH |
|---|
| Tolerance | ±10% |
|---|
| Current Rating | 680mA |
|---|
| Current - Saturation | 680mA |
|---|
| Shielding | Unshielded |
|---|
| DC Resistance (DCR) | 420 mOhm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.240" L x 0.217" W (6.10mm x 5.50mm) |
|---|
| Height - Seated (Max) | 0.193" (4.90mm) |
|---|
We can supply TE Connectivity part# MGDN2-00012. Use the request quote form to request MGDN2-00012 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MGDN2-00012. The price and lead time for MGDN2-00012 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MGDN2-00012. We look forward to doing business with you.
