Technical Specifications of SC5022C-102
| Datasheet |  SC5022C-102 datasheet |
|---|
| Category | Inductors, Coils, Chokes |
|---|
| Family | Fixed Inductors |
|---|
| Manufacturer | Signal Transformer |
|---|
| Series | SC5022C |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Part Status | Active |
|---|
| Type | - |
|---|
| Material - Core | - |
|---|
| Inductance | 1mH |
|---|
| Tolerance | ±20% |
|---|
| Current Rating | 540mA |
|---|
| Current - Saturation | 800mA |
|---|
| Shielding | Shielded |
|---|
| DC Resistance (DCR) | 2.01 Ohm Max |
|---|
| Q @ Freq | - |
|---|
| Frequency - Self Resonant | - |
|---|
| Ratings | - |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Frequency - Test | 100kHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | Nonstandard |
|---|
| Size / Dimension | 0.750" L x 0.620" W (19.04mm x 15.74mm) |
|---|
| Height - Seated (Max) | 0.300" (7.62mm) |
|---|
We can supply Signal Transformer part# SC5022C-102. Use the request quote form to request SC5022C-102 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number SC5022C-102. The price and lead time for SC5022C-102 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# SC5022C-102. We look forward to doing business with you.
